Aardwolf

Aardwolf AVLP4 PRO Four Pad 1000kg and 500L Vacuum lifter

Aardwolf AVLP4 PRO Four Pad 1000kg and 500L Vacuum lifter

Regular price $4,599.99 USD
Regular price $4,599.99 USD Sale price $4,599.99 USD
Sale Sold out
Shipping calculated at checkout.

SKU:AVLP4PRO-1

Vacuum Lifter AVLP4PRO

This item will be in stock by mid-June, 2024.

This advanced vacuum lifter is meticulously designed to accommodate the diverse needs of lifting smooth and rough marble and granite slab surfaces, embodying a superior and rugged construction. It not only facilitates the effortless lifting of heavy materials but also provides the capability to tilt them, allowing for precise positioning and handling. The core of its operation is powered by compressed air, ensuring reliable and efficient performance across various applications. This feature significantly enhances its versatility, making it an indispensable tool in environments where precision and durability are paramount, such as in workshops, construction sites, and manufacturing facilities dealing with stone materials.

* Denotes items that are not on the standard model

Features

  • Pneumatic Tilting: Enables vertical-horizontal movement from 0 to 90° for versatile handling.
  • Vacuum Tank: Provides a safety net by ensuring pickup remains secure, even if power to the vacuum pump is suddenly lost.
  • *Adjustable Handle Extensions: Press button to extend handle lengths from 76.2mm (3") to 106.68mm (4.2") for enhanced ergonomics.
  • *Energy-Efficient Design: Battery-operated energy saver intelligently controls air consumption to maximize efficiency.
  • Rechargeable Alarm System: An audio and visual alarm system powered by a *12V Li-ion battery activates when the vacuum level is low and ceases when the vacuum level reaches full capacity.
  • Convenient Air Connector: Positioned high and out of the way for easy access and minimal interference.
  • Durable Handle Construction: High-strength extruded aluminum handle encases air and vacuum lines for protection and durability.
  • *Enhanced Vacuum Pad Configuration: Supports larger items [1620.52mm (63.8") x 1094.74mm (43.1")] with options for rotating pads to accommodate various shapes and sizes.
  • Slide Valve Mechanism: Easy-to-use ON/OFF slide valve for quick attachment and release of materials.
  • *Integrated Crane Control: User-friendly crane controls are incorporated directly into the vacuum lifter handle for streamlined operation.
  • Optimal Pad Size: Equipped with vacuum pads measuring 500 x 300 mm (19.7 x 11.8 in) to suit a wide range of applications.

 Specifications for AVLP4PRO-1:


Metric
(mm-kg)
Imperial
(inch-lb)
Number of pad 4 -
Pad size 520x320 20.5"x12.6"
Working load limit Vertical: 500
Horizontal:1000
1102
2204
Net weight 109 240
Gross weight 150 331
Packaging dimensions 1680x430x960 66.1"x16.9"x37.8"



 Battery information for the AVLP4PRO-1:

Code battery GBA 12V 2.0Ah Bosch
Type battery Lithium-ION
Voltage 12V
Current 2.0Ah
Quantity 1
Continuous operation time with mode saving pressure 2 hours
Working time with mode saving pressure 6 hours
Continuous operation time with mode audio alarm only 120 hours
Working time with mode audio alarm only 360 hours


 Battery charger for the AVLP4PRO-1:

Code battery GAL 12V-40 Bosch
Input supply voltage 220-240VAC
Output voltage 12V
Output current 4.0Ah
Quantity 1
Full charger time 0.5 hour
Weight 460 gram


 Compressed air requirement for the AVLP4PRO-1:

Air consumption 180 liters/minute
Supply air pressure 5 bars (72 psi)



 Specifications for AVLP4PRO-500L:


Metric
(mm-kg)
Imperial
(inch-lb)
Number of pad 4 4
Pad size 520x320 20.5"x12.6"
Working load limit Vertical: 250
Horizontal: 500
551
1102
Net weight 112
240
Gross weight 177
390
Packaging dimensions 2250x490x1020 88.5"x19.3"x40.2"



 Battery information for the AVLP4PRO-500L:

Code battery GBA 12V 2.0Ah Bosch
Type battery Lithium-ION
Voltage 12V
Current 2.0Ah
Quantity 1
Continuous operation time with mode saving pressure 2 hours
Working time with mode saving pressure 6 hours
Continuous operation time with mode audio alarm only 120 hours
Working time with mode audio alarm only 360 hours


 Battery charger for the AVLP4PRO-500L:

Code battery GAL 12V-40 Bosch
Input supply voltage 220-240VAC
Output voltage 12V
Output current 4.0Ah
Quantity 1
Full charger time 0.5 hour
Weight 460 gram


 Compressed air requirement for the AVLP4PRO-500L:

Air consumption 180 liters/minute (6.4 CFM)
Supply air pressure 5 bars (72 psi)
