Aardwolf Vacuum Glass Lifter AVGLP2-200

$5,442.70 USD

~~$6,349.82 USD~~ $5,442.70 USD

Sale Sold out

Shipping calculated at checkout.

Part #

SKU:AVGLP2-200

Quantity

Auto Rotate Vacuum Glass Lifter AVGLP2-200

Product Code: AVGLP2-200

General

The Aardwolf Vacuum Glass Lifter is a pneumatically powered vacuum glass lifter designed to handle glass panels, even those with rough surfaces, with a lifting capacity of up to 200 kg (440 lbs). Featuring a rugged build, it offers vertical-horizontal tilting from 0 to 90 degrees, making it ideal for secure lifting in various applications.

Features

Pneumatic vertical-horizontal tilting from 0 to 90°
Automatic vacuum pumping if vacuum loss occurs
Audio/visual warning system
Attach/release materials using the ON/OFF slide valve

Specifications

Metric	Imperial
Number of pads	2	-
Pad diameter	300 mm	11.8"
Working load limit	200 kg	441 lbs
Net weight	64 kg	141 lbs
Packaging dimensions	1480 430 960 mm	58.3" 16.9" 37.8"

Battery information for the alarm system

Power supply	3.7V Lipo battery
Battery capacity	2000 mAh x 1
Standby time	720 hours
Charging cycle	1000 times
Charging time	2 hours
Non-stop working time	7 hours
6-month warranty	-
